Pro9™

Pro9 LEDs set the new standard for high fidelity (90 & 95 CRI min) LEDs

Closet Variety minimal cloths and fashion set in cloths store in Shopping mall retail asia

Pro9™ technology uses Potassium Fluoride Silicon (KSF or PFS) phosphor to boost the efficiency of LED components, especially those delivering higher CRI. Cree LED’s Pro9 LEDs are covered under a technology license from Current Lighting Solutions, LLC.

Cree LED leads the industry in using this phosphor in high-power and high lumen density LEDs, such as COBs, and is the first supplier to successfully use this phosphor in ceramic high-power LEDs.

Pro9 LEDs improve the output, efficacy and size of LED luminaires in commercial applications requiring high quality light. Pro9 LEDs have the industry’s highest operating temperature rating of 105°C and share the same mechanical and electrical characteristics to upgrade to higher CRI with no change in performance and minimal redesign.

Pro9 LEDs: COBs

Cree LED has the industry’s broadest and most extensive portfolio of Chip-on-Board (COB) LED arrays to offer our customers the perfect solution of size, power, performance and value.

Pro9 LED technology is available on all of Cree LED’s current COB families:

  • XLamp® CHA LEDs: high-intensity metal COBs with small LES
  • XLamp CMB LEDs: drop-in upgrades for Cree LED COB form factors (CXA, CXB, CMA) with the same LES & substrate sizes
  • XLamp CMU LEDs: second generation high-efficacy metal COBs in industry-compatible sizes
  • XLamp CMA LEDs: first generation metal COBs optimized for efficacy at high current
  • XLamp CXB High Density LEDs: industry’s highest lumen density ceramic COBs
  • XLamp CXB Standard Density LEDs: high-efficacy, high-reliability ceramic COBs

Pro9 LEDs: Mid-Power LEDs

J Series® Pro9™ LEDs are optimized to deliver the best value with high efficacy, with up to 24% higher efficacy over standard version LEDs.

Pro9 LEDs: Ceramic High-Power LEDs

Cree LED is the first LED supplier to deliver the efficacy increase of KSF phosphor in high lumen density XLamp high power LEDs. XLamp Pro9 LEDs deliver up to 10% higher efficacy at 90 CRI than Standard versions.

Specifications

View All
Product Type Product Data Sheet Product Status Color LES Size (mm) Voltage Class Optical Characteristics CCT Min (K) CCT Max (K) CRI Options Binning Current (A) Max Current (A) Footprint X (mm) Footprint Y (mm)
COB Metal
CHA0304 Pro9
New New White 3.3 21 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.175 0.300 13.5 13.5
COB Metal
CHA0410 Pro9
New New White 4.2 12 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.525 0.900 13.5 13.5
COB Metal
CHA0410 Pro9
New New White 4.2 36 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.175 0.300 13.5 13.5
COB Metal
CHA0612 Pro9
New New White 6 36 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.350 0.600 13.5 13.5
COB Metal
CHA0612 Pro9
New New White 6 18 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.700 1.200 13.5 13.5
COB Metal
CHA0825 Pro9
New New White 8.5 36 Fidelity, Pro9, Specialty 2700 4000 90, 95 0.700 1.200 19 19
COB Metal
CMA1303 Pro9
New New White 4.5 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.175 0.350 13.35 13.35
COB Metal
CMA1303 Pro9
New New White 4.5 9 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.700 1.400 13.35 13.35
COB Metal
CMA1303 Pro9
New New White 4.5 18 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.350 0.700 13.35 13.35
COB Metal
CMA1306
New New White 6 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.200 0.600 13.35 13.35
COB Metal
CMA1306
New New White 6 9 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.800 2.400 13.35 13.35
COB Metal
CMA1306
New New White 6 18 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.400 1.200 13.35 13.35
COB Metal
CMA1516
New New White 9 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.450 1.050 15.85 15.85
COB Metal
CMA1825
New New White 12 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.700 1.600 17.85 17.85
COB Metal
CMA1840
New New White 14 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 1.100 2.300 17.85 17.85
COB Metal
CMA2550
New New White 19 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 1.400 3.300 23.85 23.85
COB Metal
CMA3090
New New White 23 48 Fidelity, Pro9, Specialty 2700 5000 90, 95 1.800 3.600 27.35 27.35
COB Metal
CMA3090
New New White 23 72 Fidelity, Pro9, Specialty 2700 5000 90, 95 1.200 2.400 27.35 27.35
COB Metal
CMB1304 Pro9
New New White 6 9 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.400 1.200 13.35 13.35
COB Metal
CMB1304 Pro9
New New White 6 18 Fidelity, Pro9, Specialty 2700 5000 90, 95 0.200 0.600 13.35 13.35
