XLamp® COB LED Arrays

Cree LED has the industry’s broadest and most extensive portfolio of Chip-on-Board (COB) LED arrays to offer our customers the perfect solution of size, power, performance and value. Cree LED COBs have the industry’s best L90 lifetime and color stability with the data to prove it.

Cree LED Advantages

  • Largest portfolio of COBs: all major socket profiles, both metal & ceramic substrates, broadest range of LES sizes
  • Leading LPW, lumen density, lifetimes and color maintenance
  • Wide range of color options: 70, 80, 90 CRI + Fidelity & Specialty

Latest Innovations

  • Pro9™ LEDs: deliver up to 15% higher efficacy for 90 and 95 CRI over standard version LEDs without sacrificing color rendering quality. Pro9 LEDs feature the industry’s highest operating temperature rating of 105°C and the same maximum current as the standard versions.
    –  Available now on CMB, CMU, CHA, CMA & CXB LED families

Latest Technology for New Designs

  • XLamp CHA LEDs: high-intensity metal COBs with small LES
  • XLamp CMB LEDs: drop-in upgrades for Cree LED COB form factors (CXA, CXB, CMA) with the same LES & substrate sizes
  • XLamp CMU LEDs: second generation high-efficacy metal COBs in industry-compatible sizes

Legacy Product Lines

Specifications

View All
Product Type Product Family Product Product Page Data Sheet Product Status LES Size (mm) Voltage Class Optical Characteristics CCT Min (K) CCT Max (K) CRI Options Typ. Power (W) Typ lm @ 3000K, 90 CRI Typ LPW @ 3000K, 90 CRI lm @ Max Power Max Power (W) Substrate Size (mm)
COB Metal XLamp® CMA LEDs
CMA1303
Active Active 4.5 18 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 659 101 1511 15 13.35
COB Metal XLamp® CMA LEDs
CMA1303
Active Active 4.5 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 659 101 1511 15 13.35
COB Metal XLamp® CMA LEDs
CMA1303
Active Active 4.5 9 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 659 101 1511 15 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1303 Pro9
New New 4.5 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 6 833 130 1460 15 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1303 Pro9
New New 4.5 18 Fidelity, Pro9, Specialty 2700 5000 90, 95 6 833 130 1460 15 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1303 Pro9
New New 4.5 9 Fidelity, Pro9, Specialty 2700 5000 90, 95 6 833 130 1460 15 13.35
COB Metal XLamp® CMA LEDs
CMA1306
Active Active 6 9 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 773 107 2548 26 13.35
COB Metal XLamp® CMA LEDs
CMA1306
Active Active 6 18 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 773 107 2548 26 13.35
COB Metal XLamp® CMA LEDs
CMA1306
Active Active 6 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 7 773 107 2548 26 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1306
New New 6 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 7 985 137 2371 26 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1306
New New 6 9 Fidelity, Pro9, Specialty 2700 5000 90, 95 7 985 137 2371 26 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1306
New New 6 18 Fidelity, Pro9, Specialty 2700 5000 90, 95 7 985 137 2371 26 13.35
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1516
New New 9 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 16 2301 146 4878 41 15.85
COB Metal XLamp® CMA LEDs
CMA1516
Active Active 9 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 15 1818 119 5122 41 15.85
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1825
New New 12 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 24 3459 143 7170 61 17.85
COB Metal XLamp® CMA LEDs
CMA1825
Active Active 12 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 24 2849 118 7840 61 17.85
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA1840
New New 14 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 38 5275 138 9946 87 17.85
COB Metal XLamp® CMA LEDs
CMA1840
Active Active 14 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 38 4481 117 11048 87 17.85
COB Metal XLamp® CMA LEDs Pro9™ LEDs
CMA2550
New New 19 36 Fidelity, Pro9, Specialty 2700 5000 90, 95 48 6984 147 15017 122 23.85
COB Metal XLamp® CMA LEDs
CMA2550
Active Active 19 36 Fidelity, Specialty, Standard 2200 6500 70, 80, 90, 95 48 5792 122 16215 122 23.85
