Automotive & Emergency Vehicle Lighting
Automotive and emergency vehicle lighting (EVL) applications require maximum light output from the smallest possible light source. The requirements for higher light output and intensity to increase visibility and safety must be balanced with minimizing size and weight for aerodynamics. Cree LED delivers the leading LED portfolio for aftermarket automotive and EVL applications.
Key Product Lines
- XLamp® LEDs: ceramic surface-mount LEDs, including the tiny XQ & Element G (XE-G) families
- High Brightness LEDs: P4 through-hole LEDs in white, amber, orange and red
- LED Chips: A wide range of high-power, mid-power and low-power chips for blue, green and white-converted LEDs
Key Applications
- Automotive Aftermarket: Tractor-Trailer, Semi, Offroad, Motorcycle
- Emergency Vehicle Lighting: Police, Ambulance, Fire, Rescue
Specifications
No Products Found
| Product Type | Product | Data Sheet | Optimized For | Color | Optical Characteristics | Color Spec Type | Color Min | Color Max | Binning Current (A) | Binning Temp (°C) | Max Current (A) | Footprint Units | Footprint X | Footprint Y |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| P4 |
CP41A-ADS
 |
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 587 | 596 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41A-AFS
|
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 587 | 596 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41A-AHS
|
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 587 | 596 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41A-RDS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 630 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41A-RFS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 630 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41A-RHS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 630 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-ADS
|
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 584 | 599 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-AFS
|
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 584 | 599 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-AHS
|
|
Aftermarket/EVL | Amber | --- | DWL (nm) | 584 | 599 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-RDS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 637 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-RFS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 637 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-RHS
|
|
Aftermarket/EVL | Red | --- | DWL (nm) | 620 | 637 | 0.07 | 25 | 0.07 | mm | 7.6 | 7.6 |
| P4 |
CP41B-WES
 |
|
Aftermarket/EVL | White | --- | CCT (K) | 4600 | 10000 | 0.03 | 25 | 0.035 | mm | 7.6 | 7.6 |
| P4 |
CP41B-WGS
|
|
Aftermarket/EVL | White | --- | CCT (K) | 4600 | 10000 | 0.03 | 25 | 0.035 | mm | 7.6 | 7.6 |
| LED Chip |
EZ1350-p
 |
|
Auto Exterior | Royal | --- | DWL (nm) | 445 | 465 | 0.350 | 25 | 1.500 | µm | 1340 | 1340 |
| LED Chip |
EZ1950-p
 |
|
## | Royal | --- | DWL (nm) | 445 | 465 | 0.700 | 25 | 3.000 | µm | 1940 | 1940 |
| LED Chip |
EZ400-p
 |
|
Auto Interior | Royal | --- | DWL (nm) | 445 | 465 | 0.175 | 25 | 0.200 | µm | 380 | 380 |
| LED Chip |
EZ500-p
 |
|
Aftermarket/EVL | Blue | --- | DWL (nm) | 465 | 475 | 0.175 | 25 | 0.300 | µm | 480 | 480 |
| LED Chip |
EZ500-p
|
|
Aftermarket/EVL | Green | --- | DWL (nm) | 520 | 535 | 0.175 | 25 | 0.300 | µm | 480 | 480 |
| LED Chip |
EZ500-p
|
|
Auto Interior | Royal | --- | DWL (nm) | 445 | 465 | 0.175 | 25 | 0.300 | µm | 480 | 480 |
Documentation
|
|
Version
|
Last Updated
|
|---|---|---|
| 39 | 20 Dec 2024 | |
| 23 | 20 Dec 2024 | |
| 0 | 23 Sep 2022 | |
| 11 | 17 Jul 2024 |
